Compact NB-IoT module with ultra-low power consumption
Overview
Quectel BC95 is a high-performance NB-IoT module with extremely low power consumption. The ultra-compact 23.6mm × 19.9mm × 2.2mm profile makes it a perfect choice for size sensitive applications. Designed to be compatible with Quectel GSM/GPRS M95 module in the compact and unified form factor, it provides a flexible and scalable platform for migrating from GSM/ GPRS to NB-IoT network.
Quectel BC95 adopts surface mounted technology, making it an ideal solution for durable and rugged designs. The low profile and small size of LCC package allow BC95 to be easily embedded into space-constrained applications and provide reliable connectivity with the applications. This kind of package is ideally suited for large-scale manufacturing which has strict requirements for cost and efficiency.
Due to compact form factor, ultra-low power consumption and extended temperature range, Quectel BC95 is the best choice for a wide range of IoT applications, such as smart metering, bike sharing, smart parking, smart city, security and asset tracking, home appliances, agricultural and environmental monitoring, etc. It is able to provide a complete range of SMS and data transmission services to meet client-side demands.
Highlights
Compact-sized NB-IoT module
Ultra-low power consumption
LCC packaging
Temperature range -40°C to 85°C
Abundant internet service protocols
Compatible with GSM/GPRS module
Specifications
Frequency bands
BC95-B8: 900MHz
BC95-B5: 850MHz
BC95-B20: 800MHz
BC95-B28: 700MHz
Data transmission
DL: 21.25Kbps @Single Tone
UL: 15.625kbps @Single Tone
Protocol stacks
IPv4
UDP
CoAP
LwM2M
Non-IP
DTLS (under development)
Download method
UART
DFOTA
SMS
Point-to-point MO and MT
Text/PDU Mode
Maximum output power
23dBm±2dB
Sensitivity
-129dBm±1dB
Power consumption (typical)
3.6uA @PSM
2mA @Idle Mode, DRX=1.28s
LTE Cat NB1 connectivity
220mA @radio transmission, 23dBm (B8/B5/B20)
250mA @radio transmission, 23dBm (B28)
100mA @radio transmission, 12dBm (B8/B5/B20/B28)
70mA @radio transmission, 0dBm (B8/B5/B20/B28)
65mA @radio reception
Enhanced features
DFOTA: delta firmware upgrade over-the-air
RAI: release assistance indication
Interfaces
USIM x 2
UART x 2
ADC x 1
RESET x 1
Anetenna pad x 1
General features
LCC package
94 pins
Supply voltage range
3.1V-4.2V, 3.6V typical
Temperature range
-40℃ to 85℃
Dimension
23.6mm × 19.9mm × 2.2mm
Weight
1.8g±0.2g
AT command
3GPP TS 27.007 V14.3.0 (2017-03)
Quectel enhanced AT commands
Approvals
RoHS compliant
CCC/SRRC/NAL (China)
CE/GCF/Deutsche Telekom (Europe)
RCM (Australia)
NBTC (Thailand)
