Allwinner T507

Overview

Allwinner T507/T507-H is a high-performance quad-core Cortex-A53 platform SoC for the new generation of automotive markets. It integrates Cortex-A53 quad-core CPU, G31 MP2 GPU, 32-bit DDR3/LPDDR3/DDR4/LPDDR4 DRAM, multi video output interfaces (RGB/2xLVDS/CVBS OUT), and multi video input interfaces(MIPI CSI/BT656/BT1120). It supports 4K@30fps H.265 decoder, 4K@25fps H.264 encoder, DI, 3D noise reduction, SmartColor system, and keystone correction module, providing smooth user experience and professional visual effect. Allwinner T507/T507-H can be used in aftermarket like IVI and other intelligent cockpit products.

Integrate 1.4GHz 4xA53 CPU, G31 MP2 GPU, and 4GB DDR3/DDR4/LPDDR3/LPDDR4 at maximum frequency of 800MHz, providing smooth user experience and professional visual effect

Support full format video playback, 4K@30fps H.265 video decoder, and 4K@25fps H.264 video encoder

Support multi video output interfaces such as RGB888, dual link LVDS, HDMI, CVBS OUT, to achieve different display in dual screen

Integrated MIPI CSI and parallel CSI supporting maximum 8-ch HD camera inputs (maximum processing 6-ch of data at the same time) to achieve 360° AVM, DVR functions

Block diagram

Specifications

CPU

Quad-core ARM Cortex-A53, up to 1.4GHz

GPU

G31 MP2

Support OpenGL ES 3.2/2.0/1.0, Vulkan 1.1, OpenCL 2.0

Memory

32-bit DDR4/DDR3/DDR3L/LPDDR3/LPDDR4 interface, supporting maximum capacity of 4GB

SD3.0/eMMC5.0 interface

8-bit Nand flash interface with maximum 80-bit/1KB ECC

Video decoder

H.265 MP decoder up to 4K@30fps

H.264 BL/MP/HP decoder up to 4K@30fps

VP9 decoder up to 4K@30fps

AVS2 decoder up to 4K@30fps

Multi-format 1080p@60fps video playback, including VP8, MPEG1/2 SP/MP, MPEG4 SP/ASP, AVS+/AVS JIZHUN, VC1 SP/MP

Video encoder

H.264 encoder up to 4K@25fps

MJPEG encoder up to 4K@15fps

JPEG encoder up to 8K x 8K resolution

Video input

Support one 8-/10-/12-/16-bit digital camera (DC) interface

Maximum pixel clock of 148.5MHz for each DC interface

BT656, BT1120 video input for multichannel YUV

Four-lane MIPI CSI, up to 1Gbps per lane in HS transmission, compliant with MIPI-CSI2 V1.00 and MIPI DPHY V1.00

Maximum video capture resolution of 8M@30fps or 4x 1080p@25fps for MIPI CSI

Support formats YUV422, YUV420, RAW-8, RAW-10, RAW-12

Audio

Two DAC channels and four ADC channels

Support 1 audio output interface (differential LINEOUTP/N or single-end LINEOUTL/LINEOUTR)

One Audio HUB, supporting internal mixing function

Embedded 3 I2S/PCM (I2S0 for extended audio codec, I2S2 for BT, I2S3 for digital power amplifier)

Support Left-justified, Right-justified, Standard I2S mode, PCM mode, and TDM mode

I2S mode supports 8 channels, and 32-bit/192kbit sample rate

I2S and TDM modes support maximum 16 channels, and 32-bit/96kbit sample rate

One OWA IN/OUT interface, supporting 16-/20-/24-bit inputs and outputs

Integrated digital microphone, supporting maximum 8 digital PDM microphones

Display output

HDMI 2.0a up to 4K@30fps (only for T507-H)

TV CVBS output, supporting PAL/NTSC

LVDS interface with dual link, up to 1080p@60fps

RGB interface with DE/SYNC mode, up to 1080p@60fps

Security engine

Support Full Disk Encryption

AES, DES, 3DES, and XTS encryption and decryption algorithms

MD5, SHA, and HMAC tamper proofing

RSA, ECC signature and verification algorithms

Support 160-bit hardware pseudo random number generator (PRNG) with 175-bit seed

Support 256-bit hardware true random number generator (TRNG)

Integrated 2K-bit EFUSE for chip ID and security application

Connectivity

3 x USB2.0 Host, 1 x USB2.0 OTG

2 x Ethernet MAC (one 10/100 Mbps Ethernet port with RMII interface, one 10/100/1000 Mbps Ethernet port with RGMII and RMII interfaces)

SDIO 3.0, TSC, SCR, CIR Receiver

6 x TWI, 2 x SPI, 6 x UART

6-ch PWM, 4-ch GPADC, 1-ch LRADC

PMIC

Companion Allwinner Power Management IC

Package

TFBGA 421balls

15 mm x 15 mm size, 0.65 mm ball pitch, 0.35 mm ball size

Process

28nm HPC

High-performance quad-core 64-bit intelligent cockpit processor
