Allwinner T3

Quad-core vehicle navigation processor

Overview

Allwinner T3 is ideal for applications that require 3D graphics, advanced video processing, rich user interfaces, low power consumption, and a high level of system integration. Allwinner T3 delivers the kind of high level user experience we are used to in portable consumer devices and transitions it into the environment of modern vehicles. In addition to its high level of performance, it also supports driver safety features, video record feature, and an array of inputs and connectivity options for other devices.

Highlights

Content display on 4-lane MIPI DSI displays, RGB panel, or LVDS panel, TV-out via HDMI V1.4

Integrated audio codec with 24bit/192KHz DAC playback, I2S/PCM interface includes 8 channels of TDM with sampling precision up to 32bit/192KHz

Dual CMOS sensor parallel interfaces and 4-channel TVIN to execute multi-channel video recording

High-definition (HD) H.264 video encoder with a resolution of 1080p@45fps

Hardware peripherals support including CAN ,UART, RTP, SPI, CIR, USB2.0 OTG, TWI

Support Linux3.10 and Android 4.4/6.0 system

Block diagram



Specifications



CPU

Quad-core Cortex™-A7



GPU

Mali400 MP2



Display out

4-lane MIPI DSI displays, RGB panel, or LVDS panel

4-channel TV-out



Display in

Dual CMOS sensor parallel interfaces

4-channel TV-in



Video encoder

High-definition (HD) H.264 video encoder up to 1080p@45fps



Video decoder

Video decoder up to 1080p@45fps

Support multi-formats



Peripherals

USB x 3/SATA x 1

UART x 8/SPIding x 4/Smart Card x 1/TS x 2/TWI x 5

MAC x 2/PS2 x 2/KEYPAD x 1 (8 row 8 column)/IR-RX x 2/KEYADC x 2/RTP



Package

FBGA 468 balls, 0.65mm ball pitch, 16x16 mm



Operating temperature

-40℃ to 85℃



Application diagram
