Allwinner R818

Cost-efficient 64-bit intelligent hardware processor

Overview

Allwinner R818 is a powerful processor features with quad-core Cortex-A53 CPU operating with frequency up to 1.6GHz. It integrates with GE8300 GPU, H.265 4K30 video decoder for UI rendering, H.264 1080P60 encoder for media player, and 13MP camera ISP for video VOIP. Allwinner R818 also integrates with two ADCs for dual-mic voice solutions, DMIC and I2S for multi-mic solutions, and two DACs for stereo audio speaker. Moreover, Allwinner R818 supports IR transmission and IR reception for intelligent control of smart home devices. The above features together make Allwinner R818 a cost-effective solution for smart speakers with screen.

Highlights

High processor performance

Allwinner R818 features quad-core Cortex-A53 up to 1.6GHz, providing reliable computing power. It also integrates with GPU GE8300, and supports OpenGLES1.1/2.0/3.2 and Vulkan1.1.

High video performance

Video decoder H265 4K30, video encoder H264 1080P60, providing high performance for multi-media and video call.

Rich audio interface

Allwinner R818 integrates with 2 audio ADCs, 2 audio DACs, 4 I2S and 8 channel DMIC, providing flexible solutions for multi-mic array and stereo speaker.

Block diagram



Specifications



CPU

Quad-core ARM Cortex-A53 up to 1.6GHz

32KB L1 I-cache + 32KB L1 D-cache per core, 512KB L2 cache

Low-power CoolFlex power management architecture



GPU

GE8300 500MHz

Support OpenGLES1.1/2.0/3.2, Vulkan1.1, OpenCL1.2



Memory

32-bit DDR4/DDR3/DDR3L/LPDDR3/LPDDR4

eMMC 5.0

8-bit TLC/MLC/SLC/EF NAND flash

SPI NAND flash



Audio

Support two audio DAC and two audio ADC

Support two analog audio inputs and two analog audio outputs

Stereo speaker and capless stereo headphone driver

Four I2S controllers for connecting Bluetooth and external audio codec

Integrated digital microphone supporting maximum eight digital microphones



Display

Support one channel MIPI DSI output, 4-lane, up to 1920×1200@60fps

Support LVDS output with dual link, up to 1920×1200@60fps

Support RGB interface with DE/SYNC mode, up to 1920×1200@60fps

Support size up to 2048x2048, with two video layers and two UI layers

SmartColor2.0 post processing for an excellent display experience



Video

Support H.265 decoder 4k@30fps

Support H.264 decoder 1080p@30fps

Support VP8 decoder 1080p@60fps

Support H.264 HP encoder 1080P@60fps

Support MJPEG encoder 4k@15fps

Support JPEG encoder 13M



Camera

Compliant with MIPI-CSI2 V1.00 and MIPI DPHY V1.00.00

2 MIPI CSI input, 4 data lane and 2 data lane, up to 1Gbps per lane in HS

Maximum 8M@30fps or 13M@10fps, with 4 data lanes

Support YUV422-8bit/10bit, YUV420-8bit/10bit, RAW-8, RAW-10, RAW-12, RGB888, RGB565



ISP

Up to 8M@30fps or 13M@10fps, configurable as dual 1080p@60fps

Adjustable 3A functions, including AE, AWB and AF

Support spatial (2D) de-noise filter

Support contrast enhance and sharping

Support chrominance noise reduction

Support defect pixel correction



Security

Support symmetrical algorithm including AES, DES, 3DES, XTS, SM4

Support hash algorithm including MD5, SHA, HMAC, SM3

Support asymmetric algorithm including RSA, ECC, SM2

Support PRNG and TRNG

Support 2K-bit EFUSE for chip ID and security application



Connectivity

USB 2.0 OTG and HOST, SDIO 3.0, GMAC

SPI×3, TWI×5, UART×6, PWM×5

IR TX, IR RX, LEDC, GPADC, LRADC



PMIC

AXP803 with charger

AXP806 without charger



Package

LFBGA 346 balls

12mm x 12mm size, 0.5 ball pitch, 0.3 ball size



Process

28nm HPC+



OS

Android 10
