Allwinner R58

A hybrid PC, also called “2-in-1” or “detachable”, has a removable screen that turns into a tablet when separated, capable of delivering both the productivity of laptop and the mobility of a tablet in a single device. To meet the increasing need for laptop-tablet versatility, the octa-core high performance Allwinner R58 processor is designed for hybrid PCs, supporting things from productive tasks to gaming and HD video streaming.

To deliver the performance and productivity of a laptop, Allwinner R58 packs eight Cortex-A7 CPU cores with clock speed up to 2.0GHz and an ultra-fast PowerVR SGX544MP GPU architecture to enable remarkable computing capability.

Allwinner R58 delivers exceedingly high system integration for better device mobility, including LPDDR3/LPDDR2 interface, LVDS, MIPI DSI, HDMI, and HawkView ISP. It also comes with features including multi-format high-definition 1080p@60fps video processing, 2048x1536 resolution display, and 8M camera support for excellent entertainment experience. The SmartColor display technology is also supported to enhance color, contrast and resolution, providing users with spectacular visual experience. Moreover, R58 implements a TrustZone-based security system to address the increasing need for more reliable system in applications such as mobile payment and copyright protection.

Extremely low power consumption is another noteworthy feature of Allwinner R58. Thanks to its performance-power balanced system architecture, ultra-high system integration, and cutting-edge 28nm process, Allwinner R58 consumes less power than quad-cores, capable of delivering long-lasting on-the-go working and entertainment experience to end users.

Allwinner R58 runs on deeply customised Android operating system to improve productivity and entertainment experience.

PowerVR SGX544 GPU

Support OpenGL ES 2.0/1.1, OpenCL 1.1, DX 9_3

Support H.264 1080p@60fps or 720p@120fps video capture

Support LVDS 1366x768@60fps or RGB LCD 2048x1536@60fps

Support 4-lane MIPI DSI 1920x1200@60fps

Support HDMI 1080p@60fps and HDCP V1.2

Support dual-display LCD 720p@60fps and HDMI 720p@60fps

Integrated 5MP parallel CMOS sensor

Integrated 8MP MIPI CSI controller

Integrated 8MP ISP

Support SLC/MLC/TLC/EF NAND with 64-bit ECC

Support eMMC V4.5

USB Host, USB Dual-Role (host/device)

Ethernet MAC

2x SPI, 4x TWI, 6x UART, RSB

3x SD/MMC

HSIC

2x I2S/PCM

CIR, LRADC
