Allwinner R16

Competitive quad-core IoT solution

Overview

Allwinner R16 is an efficient quad-core solution designed for IoT applications, which outperforms competitors in terms of its system performance, scalability, and energy-efficiency.

Allwinner R16 packs four ARM Cortex-A7 CPU cores and Mali400MP2 graphics architecture to enable impressive system performance, and it perfectly supports various applications of mainstream operating systems such as Android and Linux.

To deliver better architecture scalability, R16 comes with an extensive connectivity and interfaces, including eight groups of GPIO, six UARTs, two SPIs, four TWIs, 4-lane MIPI DSI, LVDS, USB OTG/HOST, SD/MMC, I2S/PCM, RSB, and a lot more. Allwinner R16 is designed to be extremely power-efficient to realise massive ubiquitous deployment. It achieves lower power consumption with a balanced combination of several features: the exceedingly power efficient Cortex-A7 CPU cores, the advanced fabrication process, the battery-saving DVFS technology support, and the low power design architectures.

Highlights

Block diagram

Specifications

CPU

Quad-core Cortex™-A7

256KB L1 Cache

512KB L2 Cache

GPU

Mali400

Support OpenGL ES 2.0 / VG 1.1 standards

Video

Support 1080p@60fps video playback

Support multi-format FHD video decoding, including Mpeg1/2, Mpeg4 SP/ASP GMC, H.263, H.264, WMV9/VC-1, VP8

Support H.264 High Profile 1080p@60fps encoding

Comply with RTSP, HTTP, HLS, RTMP, MMS streaming media protocols

Support OpenMax protocol

Display

Support 1/2/4-lane MIPI DSI up to 1280x800 resolution

Support MIPI DSI V1.01 and MIPI D-PHY V1.00

Support command mode and video mode (non-burst mode with sync pulses, non-burst mode with sync event and burst mode)

Support RGB/CPU/LVDS LCD up to 1280x800 resolution

Camera

Integrated parallel camera sensor interface

Support 5M CMOS sensor

Support 8-bit YUV sensor

Memory

Support 16-bit two ranks DDR3/DDR3L SDRAM controller, supports memory capacity up to 2GB

Support 8-bit NAND Flash controller

Support MLC/TLC/SLC/EF-NAND, 2 flash chips, ECC 64-bit

Audio

Integrated Hi-Fi audio codec

Two integrated differential analog mic amplifiers for headset and phone
