Allwinner R11

Competitive small-screen dual-mic voice interaction solution

Overview

Allwinner R11 integrates a single-core ARM CortexTM-A7 CPU that operates at speed up to 1.2GHz. A 64MB DDR2 is embedded in Allwinner R11. Allwinner R11 includes full functions such as dual-mic voice interaction, 720p screen display, slide and touch interaction, and 720p video record. The integrated video engine supports H.264 1080p@30fps decoder and H.264 720p@60fps encoder. Audio subsystem includes integrated audio codec and I2S/PCM/TDM interface. Allwinner R11 includes rich interfaces such as MIPI CSI, DVP camera interface and RGB/LVDS LCD output. Besides, R11 can support TINA OS and MINI GUI. Allwinner R11 is qualified to industrial standard in white electricity industry.

Highlights

Dual-mic middle-near field intelligent voice interaction

Allwinner R11 integrates ADC, DAC, and I2S/TDM interface, supporting FPU and NEON, which meets the requirements of dual-mic noise reduction, AEC, wake-up, local command word algorithm, cloud ASR, and IoT interaction. Allwinner R11 is an ideal choice of middle-near field voice interaction solution.

720p display and touch interaction

Allwinner R11 integrates a 720p@60fps RGB/LVDS interface and an H.264 1080p@30fps video decoder, providing robust support for on-line media playback. Additionally, it is compatible with TINA OS and MINI GUI, ensuring versatile functionality and a wide range of application possibilities for various multimedia and graphical user interface requirements.

Powerful camera functions

Allwinner R11 integrates MIPI CSI, DVP, 5M ISP, and an H.264 720p@60fps encoder, enabling on-line video calling and image identification functions. This powerful combination ensures seamless video communication and accurate image processing for real-time visual interactions and intelligent image recognition.

Block diagram



Specifications



CPU

ARM® Cortex™-A7 @1.2GHz



Video

Support H.264 encoder up to 720p@60fps

Support H.264 and JPEG/MJPEG decoder up to 1080p@30fps



ISP

Integrated ISP up to 5M pixels

Support two channel outputs for display and encoding respectively

Support various input and output formats

Support AE/AF/AWB

Support saturation adjustment / noise reduction / defect pixel correction / distortion correction



Video input/output

Support 8/10/12-bit parallel CSI and 2-lane MIPI CSI2

Support BT1120 input

Support capture resolution up to 5M with parallel interface

Video capture resolution up to 1080p@30fps

Support RGB LCD output, up to 1024x768@60fps



Memory

SIP 16-bit DDR2



Audio codec

Support two ADC channels and two DAC channels

Support one stereo headphone output

Support one differential microphone input



Security engine

Support AES/DES/TDES, SHA1, and MD5



Connectivity

SDIO, LRADC, SPI, TWI, UART, PWM, USB



OS

Support Linux OS



Package

eLQFP 128 (including one built-in DDR2)
