Allwinner A133

Quad core tablet application processor

Overview

Alwinner A133 is a highly-integrated application processor designed for mainstream tablet applications. It integrates quad-core 64-bit Cortex-A53 CPU and Imagination PowerVR GE8300 GPU to ensure rapid response and smooth running for daily applications, such as online video, web browsing, and 3D gaming.

Alwinner A133 supports the DRAM controller interface (LPDDR2/DDR3/DDR3L/LPDDR3/DDR4/LPDDR4, and maximum capacity up to 4 GB), eMMC, NAND, and SPI NAND flash. These rich memory interfaces enable customers to implement flexible configuration based on different requirements for tablet solutions. It also provides rich peripheral interfaces, such as MIPI-DSI/RGB/LVDS panel interface, MIPI- CSI camera interface, USB, UART, TWI, I2S, GPADC, etc.

Highlights

Powerful Operation Capacity

Allwinner A133 integrates quad-core 64-bit Cortex-A53 CPU up to 1.7 GHz, which has more powerful performance to ensure rapid response of daily application than A35 CPU. It adopts the CoolFlex low-power design architecture and dynamic power consumption management technology to enable excellent energy efficiency ratio. The integrated Imagination PowerVR GE8300 GPU can easily meet the computing requirements of various mainstream graphics. The GPU API supports OpenGL ES 3.2/Vulkan 1.3 /OpenCL 1.2 and meets the certification requirements of the latest Android GMS.

Powerful Multimedia Capacity

Allwinner A133 supports mainstream video decoding such as H.265/VP9/H.264 (H.265/H.264 maximum performance up to 4K@30fps), H.264 video encoding up to 1080p@60fps, display output up to FHD 1920 x 1200@60fps, and Allwinner SmartColor 2.0 display enhancement technology to provide excellent video experience for users. Analog audio interfaces support 2 ADC, 2 DAC, stereo headphone, and digital audio interfaces support I2S, DMIC, OWA, which meet the requirements of mainstream audio recognition solutions.

Built-in 13M ISP

Allwinner A133 supports front and rear MIPI CSI cameras, and one built-in 13M ISP which can support mainstream camera module in the market while meeting the photography requirements of the medium-low tablet.

Block diagram



Specifications



CPU

Quad-core ARM Cortex-A53@1.7GHz

32 KB L1 I-cache + 32 KB L1 D-cache per core, 512 KB L2 cache

Low-power CoolFlex power management architecture



GPU

IMG PowerVR GE8300

Support OpenGL ES3.2, Vulkan1.3, OpenCL1.2



Memory

LPDDR2/DDR3/DDR3L/LPDDR3/DDR4/LPDDR4, 32-bit width, maximum memory capacity

Up to 4 GB eMMC 5.1, 8-bit parallel NAND Flash, SPI Nand flash



Video

H.265 video decoder 4K@30fps, H.264 video decoder 4K@30fps, VP9 video decoder 720p@30fps

H.264 video encoder 1080p@60fps

MJPEG/JPEG Baseline encoder 4K@15fps



Display

MIPI-DSI interface, dual-link LVDS interface, RGB interface

Maximum resolution for the display is 1920 x 1200

Allwinner SmartColor2.0 post processing for an excellent display experience



Camera

4 lanes MIPI-CSI@1.0Gbps

13M@10fps or 8M@30fps ISP, supporting 3A/2D de-noise/defect pixel correction



Audio

2 DAC and 2 ADC

LINE-OUT/MIC-IN/Stereo headphone

4 I2S, 8 channel DMIC, OWA OUT



Connectivity

2 USB2.0 (USB Host x 1, USB OTG x 1)

SDIO 3.0

SPIx3, UARTx6, TWIx6, PWM (5-ch)

EMAC, GPADC, LRADC, CIR RX&TX



PMIC

Customized AXP717



WIFI/BT

Allwinner XR829 802.11 b/g/n + BT4.2, or AW869A 802.11 a/b/g/n/ac + BT 5.0



OS

Android 10.0 and above



Package

LFBGA 346balls

12mm x 12mm body size, 0.5mm ball pitch, 0.3mm ball size



Application diagram
